6X6MM 1080P 720P Super Mini AHD Camera Smallest Security Surveillance CCTV Video Camera For FPV HD AHD DVR CCTV System




![]()
Warnning Before Order:
*** This is AHD Camera, Which must work with correct AHD DVR. ***
Please follow below guidance (IMPORTANT):
- If you buy my 720P camera, it must work with at least AHD 720P or higher resolution AHD DVRs, the common old analog DVR and other TVI CVI DVRs are not ok,otherwise camera will not display pictures.
- If you buy my 1080P camera, it must work with at least AHD 1080P or higher resolution AHD DVRs, both 720P AHD DVR and Common old Analog DVR /TVI CVI DVR are not ok, otherwise Camera will not display pictures.
- This camera can not connect with monitor directly, it must connect though AHD DVR.
-This camera not have ir night vision ,don't have ir leds ,not support audio pls know this
You will take responsibility for your wrong order if camera does not fit for your DVR system. We will not agree the dispute of return or refund for this reason.
WHAT'S THE ADVANTAGE OF AHD CAMERA?
Features:
1.AHD 720p (1.0MP) or 1080p(2.0MP) option
High Resolution : 1280*720(1MP Camera) or 1920*1080(2MP Camera)
2. 3.6mm HD lens, provide a wide view angle 85 degree
3. Color HD-AHD, Color image at day time, no night vision picture.
4. It works with AHD DVRs only (720p camera works with 720P or above AHD DVR, 1080p camera works with 1080P or above AHD DVR). Do not connect it with traditional analog DVR or monitor directly, otherwise the picture will not display.
Specifications:
|
Model |
AHD 720P (Models:GS-A6CH) |
AHD 1080P (Models:GS-A6CM) |
|
Resolution |
1.0 Megapixels |
2.0 Megapixels |
|
Sensor |
1/4 inch sensor |
|
|
Minimum Illumination |
color:0. 01Lux'(F1.2,AGC ON) |
|
|
NO NIGHT VISION PICTURE |
||
|
Video compression |
H.264,support dual stream,AVI;0.1M~6Mpbs variable;1~30f/s variable |
|
|
Video Signal |
PAL/NTSC optional , default PAL |
|
|
Video Resolution |
1280×720@25FPS |
1920x1080@25FPS |
|
Shutter |
1/50(1/60) seconds to 1/10,000 seconds |
|
|
lens |
3.6mm , View angle 85 degree |
|
|
Day and Night |
No infrared night vision image (Do not advise for night vision) |
|
|
Audio |
not have |
|
|
Synchronous Mode |
inter-sync |
|
|
Noise-signal Ratio |
>58dB |
|
|
Temperature and Humidity |
- 10’C ~ 60’C, humidity is less than 90% (no condensation) |
|
|
Auto iris |
No |
|
|
Other function |
Indoor use only, not waterproof |
|
|
Power |
DC12V 1A input, power consumption:≤3W (Power adapter is NOT included in package) |
|
|
Camera Dimension |
6x6mm |
|
|
Housing material |
just camera pcb ,no housing |
|
Package include:
1PCS x AHD camera
(DC12V1A power adapter is NOT include, you can buy separate DC12V power adapter in our store if need)
How to Connect with AHD DVR:
