HD 700TVL Mini Camera CCD Analog Camera Home security camera Mini Cctv Camera Indoor Video Camera Support Privacy Occlusion
Specifications:
700TVL Hi-res Mini Square Camera
1. Wide voltage: DC12V
2. Low Illumination: 0.01LUX
3. With OSD menu
---1/3” SuperHAD II CCD + 700TVL
---Wide range power supply DC 5-15v, more convenient for different applications
---Low Current Frequency
---Nice back light compensation and good image, used for the ATM surveillance or under sharp contrast in lighting conditions like aeria video
Specification Of the Camera:
|
Image Device |
1/3” Super HAD II CCD |
|
|
Number of Pixels |
PAL : 752(H) x 582(V) 440K / NTSC :768(H) x 494(V) 380K |
|
|
Scanning System |
PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec |
|
|
Sync System |
Internal Synchronization |
|
|
Horizontal Resolution |
700 TV Line |
|
|
Minimum Illumination |
0.01Lux |
|
|
S/N Ratio |
More Than 48dB |
|
|
Gamma Characteristic |
0.45 |
|
|
Video output |
1Vp-p 75 Oms , Negative |
|
|
Lens |
3.6mm board lens by defaut |
|
|
(wide angle lens, pinhole lens for option) |
||
|
Electronic Shutter |
PAL : 1/50~1/100,000 Sec; NTSC : 1/60~1/100,000 Sec, auto |
|
|
Working Voltage/Current |
DC 5-15V / 60mA-130mA |
|
|
Housing |
Black |
|
|
Dimension |
25x 25mm |
|
|
OSD Menu (On Screen Display) functions |
Exposure |
ON/OFF |
|
White Balance |
Adjustable |
|
|
BLC |
Adjustable |
|
|
Day&Night |
Color / B/W |
|
|
DPC |
ON/OFF |
|
|
Motion Detection |
ON/OFF |
|
|
Privacy |
Available |
|
|
Parking Line |
ON/OFF |
|
|
Language |
Selectable |
|
If the buyer want other sizelens please 'Leave Message to Seller' to notify us when bidding.
Thanks for your attention to our products.if you have any question ,pls fell free to contact with us !
we will replyed you within 24hours!!!
Below Lens,some of them can be replaced for different angle view &distance requirement ! pls talk with us whetherit is available for the camera !
